VanGuard 1321BRI Brightfield Clinical Microscope with Binocular Head, Halogen Illumination, 4X/10X/40X/100X Magnification, 360 Degree Viewing Angle Reviews


Other Picture
VanGuard 1321BRI Brightfield Clinical Microscope with Binocular Head, Halogen Illumination, 4X/10X/40X/100X Magnification, 360 Degree Viewing Angle Feature
- Intergrated koehler illumination
- Advanced ergonomics; small footprint
- High-eyepoint eyepieces (FD 20mm) with rubber eyecups
- Measures 370mm length by 190mm width by 400mm height
- 5-Year optical/mechanical, 1-year electrical warranty
The vivid, infinity-corrected optics of the VanGuard 1300-Series Clinical Microscopes offer exceptionally high optical flatness and visual clarity. Ultra-low focusing controls and advanced ergonomics make them an excellent match for use in medical/veterinary clinics, universities, and industrial laboratories. Specifications: optical system: VIOS infinity-corrected, head: binocular, objective magnification: 4X, 10X, 40X, 100X (Oil), objective type: plan achromatic, infinity optics: yes, brightfield: yes, phase contrast: no, darkfield: no, koehler: yes, viewing head: 30 degree inclination; 360 degree rotatable, interpupillary adjustment: 55-75 mm, dioptric adjustment: -6 to +6, eyepieces: 10X super widefield; 20 mm F.D.; high-eyepoint; rubber eyecups, nosepiece: 4-position; reverse pitch, objectives: plan achromatic; 4X (0.10 N.A.), 10X (0.25 N.A.), 40X (0.65 N.A.), 100X (1.25 N.A.); DIN standard, stage: rectangular 140 x 130 mm mechanical; drop-down, right-hand, rack and pinion X-Y control, 75 x 50 mm cross travel range; removable spring-clip slide holder; chemical-resistant finish, focusing: coaxial, ultra-low position, coarse/fine controls; tension adjustment; safety auto-stop; 20 mm focusing range; 0.002 mm precision, condenser: 1.25 N.A. abbe; iris diaphragm; rack and pinion focusing control, illumination: 20 W variable quartz halogen; centerable field diaphragm for koehler; filter holder on collector; removable collector for simple lamp replacement, base: 225 x 175 mm; anti-skid rubber feet, body: ergonomic; stain-resistant enamel finish, weight: 6.5 kg, voltage: 110 volts, supplied with: dispersion filter, blue filter, spare lamp and fuse, eyecups (2 ea.), dust cover, and operation manual.
